tiny house tRAILERS

We're proud to work with Iron Eagle Trailers out of Portland, Oregon for our trailers.  Iron Eagle is a leader in the tiny home industry, and their trailers are engineered and built specifically for tiny houses. Scroll down to see why we use Iron Eagle Trailers.





Please select the link to the right to download Iron Eagle PAD Trailer Specifications PDF

WHY WE CHOOSE IRON EAGLE TRAILERS

SUPERIOR DESIGN -- Trailers designed and built specifically for tiny houses. Every detail of the frame is tailored for supporting a tiny house structure and its contents. For example, the crossmember supports are recessed six inches below the top of the frame to accommodate 2x6 floor joists and insulation to eliminate thermal bridging without sacrificing any floor height. The frame is pre-drilled to anchor your floor joist ledgers and wall bottom plates. The axles are positioned significantly forward compared to a typical flatbed trailer. A tiny house distributes its weight on a trailer frame much differently than typical cargo so we've determined the optimal axle offset that's best suited to accommodate a tiny house. Our design isn't simply a modified flatbed; it's designed from the ground up for one purpose only . . . to be the ultimate foundation for your tiny house.

WIDER -- When it comes to tiny living, every inch of extra space matters. The overall width of the fenders are at the maximum legal limit of 8'-6'' (102''). We've also extended the width of the frame ahead of and behind the fenders to 8'-4'' (100'') to maximize usable space. We've intentionally left the frame side extensions 2 inches narrower than the legal limit to accommodate the thickness of exterior siding and trim to remain within the legal highway width limit. If your plans require the frame to be narrower than the standard 100", no problem. We can build the trailer with frame extensions widths of 98", 96", 94", 92", 93", or 90" at your request without additional charge.

STRONGER -- Nearly 100% of the frame is constructed of square and rectangular tubing. There are many types of steel that can be used in the construction of a trailer frame. Tubing has the most resistance to twisting compared to other common types of steel. We've chosen tubing as the main component for the frame due to its superior ability to remain flat and rigid despite the inevitable uneven loads that your tiny house will impose on it.

LIGHTER -- The less your tiny house trailer weighs, the more your house can weigh, it's that simple. A standard flatbed car hauler type trailer is structurally built with far too much weight where it's not needed (between the fenders) as far as a tiny house is concerned. They're built well for their intended purpose - hauling cars & equipment - but not for a tiny house. The structural weight of our tiny house trailers is concentrated at the outside of the frame to support your walls and roof. The inside of the frame requires very little load bearing load bearing support so we install smaller and lighter cross members to minimize weight. Our 20' tiny house trailer weighs less than 1800lbs. A typical 20' equipment hauling flatbed trailer weighs in excess of 2300lbs and it's still much narrower than our dedicated tiny house trailer.

ENERGY EFFICIENT -- A tiny house built on a trailer that has not been designed to minimize the effect of thermal bridging will cost more to heat in the winter and cool in the summer. Steel is an excellent conductor of heat. Any metal framework that's in direct contact with your subfloor, no matter how much insulation is installed will reduce the energy efficiency of your tiny home. Our frame design significantly reduces the proximity of steel framework to your living space.

MORE SIZES -- We build an extensive selection of tiny house trailer sizes. All of our tiny house trailers have a standard frame width of 100 inches. The trailer lengths vary, ranging from 10ft to 30ft in 2 foot increments. Our 10' and 12’ long trailer is equipped with a single 5000 Lb rated axle. The 14' through 20' trailers are equipped with tandem 5,000 Lb rated axles. The 22' through 26' trailers are equipped with tandem 7,000 Lb rated axles. Our 28' and 30’ trailers are equipped with triple 7,000 Lb rated axles. Radial tires and all wheel brakes are standard features on every trailer we make. Even though we offer a wide range of sizes, we've made choosing the right trailer surprisingly easy. 95% of choosing the right tiny house trailer is simply letting us know what the length of your tiny house is.

SUPERIOR VALUE -- We're simply the best at what we do and we do it for less. We've seen a lot of tiny house trailers over the years so we know what's out there. We've talked to hundreds of tiny house builders about their needs and concerns. We've collaborated with experts in dozens of organizations dedicated to tiny house construction. All of which has helped us to create the best design available anywhere. In essence, we are the best choice for your tiny house trailer.
